AML Covers Over 650 Individual Aircraft

The FAA has awarded an STC to Garmin for the G5 electronic flight instrument for installation as a replacement directional gyro (DG) or horizontal situation indicator (HSI) in type-certificated fixed-wing general aviation aircraft. When paired with select VHF NAV/COMMs or GPS navigators, the G5 can be considered primary for displaying magnetic heading, VOR/LOC guidance and/or GPS course guidance, as well as distance and groundspeed. The installation of dual G5 electronic flight instruments can also eliminate the dependency on a failure-prone vacuum system. Installation approval is accomplished via supplemental type certificate (STC) with a comprehensive approved model list (AML) containing over 650 individual aircraft models, which is representative of the FAA's commitment to encourage and authorize specific enhancements to aircraft to improve safety among the existing general aviation fleet.

Comprising of a bright, 3.5-inch sunlight readable liquid crystal display (LCD), the G5 electronic flight instrument is approved for installation in place of the aircraft’s existing DG/HSI via a Garmin-held STC for hundreds of certificated fixed-wing aircraft models. Utilizing the new cost-effective magnetometer, the G5 electronic flight instrument displays magnetic heading. A dedicated rotary knob allows pilots to easily select and adjust course and make heading bug selections. Suitable for installation in place of a standard 3-1/8-inch flight instrument, the G5 measures 3-inches in depth with the back-up battery so it can easily be integrated into a wide range of aircraft. The G5 electronic flight instrument is also approved for flight under VFR and IFR conditions, offering an economical upgrade for thousands of aircraft owners.

When paired with the GTN 650/750, GNS 430W/530W, non-WAAS GNS 430/530 and GNS 480 navigators, the G5 is approved as a primary source to display vertical and lateral GPS/VOR/LOC course deviation when available, as well as groundspeed and distance to the next waypoint. In a G5 configuration that is paired with the GNC 255 or SL 30 NAV/COMM radio, the G5 is approved as a primary source to display lateral and vertical course deviation when available. Additionally, a single magnetometer is capable of supplying magnetic heading information to two G5 electronic flight instruments simultaneously.

The G5 electronic flight instrument offers a wide range of flexible panel configuration options and the reliability associated with a modern electronic flight instrument. Installation configurations vary as up to two G5 displays can be incorporated into a single aircraft panel in several approved combinations, including the attitude, DG/HSI or turn coordinator positions. In dual installations, a secondary G5 can revert to display attitude information in the unlikely event of a failure in the primary attitude indicator position. A pilot-selectable menu on the G5 DG/HSI enables the manual selection and interchange between the attitude indicator and DG/HSI display. Each G5 for certificated aircraft includes a four-hour back-up battery for use in the event of an aircraft electrical system failure. In dual G5 configurations, customers receive dual ADAHRS and dual back-up batteries, offering safety-enhancing redundancy.

The G5 DG/HSI electronic flight instrument for certificated fixed-wing aircraft can be purchased through the Garmin authorized dealer network starting at $2,449, which includes the install kit, magnetometer, back-up battery and the STC. When interfaced with a compatible GPS navigator, the G5 DG/HSI electronic flight instrument is available with the required adapter for $2,975. A combination of dual G5 electronic flight instruments for certificated aircraft is available for $4,598.

(Image provided with Garmin news release)

FMI: www.garmin.com/aviation
